Crucible Furnace
- Brand Name: Luwei
- Model: Glass Melting Crucible Furnace 1600°C
- Max.Temperature: 1600°C
- Working Temperature: 1500°C
- Furnace Chamber Size: 200*200*200MM
- Temperature Controller: PID and SCR
- Control Accuray: ± 1°C
- Heating Element: MoSi2 rods
- Thermocouple: B type
- Chamber Material: High purity Ceramic fiber
Crucible Furnaces are one of the oldest and simplest types of melting furnace unit used in the foundry. The Crucible Furnaces uses a refractory crucible which contains the metal charge. The charge is heated via conduction of heat through the walls of the crucible. The heating fuel is typically coke, oil, gas or electricity. Crucible Furnaces are typically classified according to the method of removing the metal from the crucible.
Crucible Furnace is designed for easy maintenance and convenient operation. The efficient design allows for dependability and durability. Insulation aids in heating uniformity for precise, uniform temperature control which is required for today’s high-temperature processes. This unit automatically sets the PID values for your thermal process.
Electric Laboratory Glass Melting Crucible Furnace is mainly used in the high temperature fusion of block and powder materials to obtain a variety of new formulas and new materials for the performance test of new materials.
The temperature Category: 1200°C 1400°C 1600°C 1700°C 1800°C. We support OEM Orders for you!
Technical Specifications of Crucible Furnace |
|
Crucible Size |
1L, 3L, 5L, 10L, 15L, 20L |
Max. temperature |
1600°C (<2hour) |
Working temperature |
1500°C |
Temperature controlling |
PID automatic control via SCR (Silicon Controlled Rectifier) power control with phase angle fired, current limiting resistor. |
16 programmable segments for precise control of heating rate, cooling rate and dwell time. |
|
Built in PID Auto-Tune function with overheating & broken thermocouple broken protection. |
|
Over temperature protection and alarm allows for operation without attendant. |
|
Temperature accuracy |
±1°C |
Temperature Uniformity |
±5°C |
Heating rate |
0-15°C/min |
Thermocouple |
B type |
Heating element |
MoSi2 heating elements |
Furnace Chamber |
Three layers of ceramic fiber insulation materials |
Furnace structure |
Double layer steel casing with dual cooling fan, surface temperature below 60°C |
Furnace door |
Front-side open |
Power cutting off when furnace door open |
|
Working voltage |
220V or 380V, 50HZ or 60HZ |
Rated power |
8 KW |
N.W/G.W |
280KG/350KG |
Stander crucible size (mm) customize |
1L,3L,5L,10L,15L,20L |
