Sintering Furnace
- Brand Name: Luwei
- Model: 1100°C Degree Sintering Furnace
- Max.Temperature: 1200°C
- Working Temperature: 1100°C
- Furnace Chamber Size: 200*200*200MM
- Temperature Controller: PID and SCR
- Control Accuray: ± 1°C
- Heating Element: SiC rods
- Thermocouple: S type
- Chamber Material: High purity Ceramic fiber
Sintering is the process of compacting and forming a solid mass of material by heat or pressure without melting it to the point of liquefaction. Sintering happens naturally in mineral deposits or as a manufacturing process used with metals, ceramics, plastics, and other materials. Luwei Furnace Company designs and builds Sintering Furnaces around our clients’ manufacturing needs – the time, temperature and atmosphere requirements for their specific product manufacturing process.
Sintering Furnaces is mainly for laboratory industrial and mining enterprises scientific research units for element analysis, and measured small size steel hardening, annealing, tempering of heat treatment for heatingfurnaces. Sintering Kilns can also be used as a metalceramic sintering dissolution and analysis of high heating use.
Sintering Furnaces is High purity alumina fiber insulation and Morgan materials brick PID automatic control via SCR (Silicon Controlled Rectifier), power control with phase angle fired current limiting resistor and 16 programmable segments for precise control of heating rate.
The temperature Category: 1200°C 1400°C 1600°C 1700°C 1800°C.
Technical Specifications of Sintering Furnace |
|
Chamber size |
200x200x200mm (Width * Height * Depth) (8 Liter) |
Max. temperature |
1200°C (<2hour) |
Working temperature |
1100°C |
Temperature controlling |
PID automatic control via SCR (Silicon Controlled Rectifier) power control with phase angle fired, current limiting resistor. |
16 programmable segments for precise control of heating rate, cooling rate and dwell time. |
|
Built in PID Auto-Tune function with overheating & broken thermocouple broken protection. |
|
Over temperature protection and alarm allows for operation without attendant. |
|
Temperature accuracy |
±1°C |
Temperature Uniformity |
±5°C |
Heating rate |
0-15°C/min |
Thermocouple |
S type with 99.7% purity Alumina tube |
Heating element |
SiC heating elements |
Furnace Chamber |
Three layers of ceramic fiber insulation materials |
Furnace structure |
Double layer steel casing with dual cooling fan, surface temperature below 60°C |
Furnace door |
Front-side open |
Power cutting off when furnace door open |
|
Working voltage |
220V or 380V, 50HZ or 60HZ |
Rated power |
5 KW |
N.W/G.W |
120KG/170KG |
Stander chamber size (mm)customize |
100*100*100 150*150*150 200*200*200 300*200*200 300*300*300 400*300*300 400*400*400 500*400*400 500*500*500 600*500*500 |
