Industrial Kilns

  • Brand Name: Luwei
  • Model: KSS-1200P Industrial kiln
  • Max.Temperature: 1200°C
  • Working Temperature: 1200°C
  • Furnace Chamber Size: 1800x1200x1200mm
  • Temperature Controller: PID automatic control via SCR
  • Control Accuray: ± 1°C
  • Heating Element: MoSi2 heaters
  • Thermocouple: S type
  • Chamber Material: High quality heat resistant alumina ceramic plates with 50mm thick and mullite bricks
Send Message Get Price
Description of Industrial Kilns

Luwei Industrial Kilns’ giant capability electrical kilns and gas kilns are designed with extra strength and insulation that allows the kilns to fireplace to high temperatures and maintain those temperatures while not injury or deterioration. Luwei Industrial Kilns builds cheap, powerful electrical and gas kilns for industrial, industrial and production volume use. Our Industrial gas and electrical kilns have several outstanding options together with style choices of high or front loading, or automotive loading with a removable floor and door for convenient loading and unloading.

Industrial Kilns

Industrial kiln is additionally known as as shuttle chamber and pottery kiln in china. Industrial kiln is welded by steel and profiled steel. Industrial kiln chamber is ceramic fiber and top quality resistance wire carbide which may save eightieth energy-saving than refractory bricks kiln chamber. Industrial kiln is especially used for hardening normalizing and stress relieving of bars and tubes forgings giant weldments and castings.

Industrial Kilns

Features of Industrial Kilns

Luwei Industrial Kilns is focused on understanding our customer’s thermal equipment needs and working to supply the best Industrial Kilns to meet those needs at the most competitive price. By applying the latest proven technology, Luwei Industrial Kilns is able to provide innovative solutions that meet or exceed our customer’s expectations in equipment quality, production efficiency and operational economy.

Industrial Kilns

Technical Specifications of Industrial Kilns

Furnace construction

Energy,furnace chamber used Morgan materials imported fibers, high purity ceramicfiber insulation( energy saving 40% and weight lighter about 50% than old furnace).

Big yield capacity and high productivity, especially used for heating treatment of small or medium products.

Double layers carbon steel casing with fan cooling to ensure the surface of furnace below 50°C

Chamber size

1800(L)*1200(W)*1200(H)

Max. temperature

1200°C (<2hour)

Working temperature

RT=1000°C ( >5 hrs)

Kiln open mode:

Front loading trolley kiln with manual operation

Temperature controlling

30 segments programable and PID auto control

Heating elements:

High performance SIC heater with three sides or four sids

Thermocouple:

Long Life S Type Thermocouple

Heating rate

0~20°C / min (suggestion =< 10°C)

Temperature accuracy

±1°C

Wok voltage:

AC220V/380V, 50/60Hz(or as your requirement)

Furnace temperature field uniformity

±1℃( according to the heating chamber size and can multi point temperature control)

Temperature controller :

SCR control, PID parameter self-setting function rapid temp compensation.

30 programmable segments for precise control

Built in protection for over-heated and broken thermal couple.

Large digital control panel for easy operation

Furnace chamber materials:

High quality heat resistant alumina ceramic plates with 50mm thick and mullite bricks

Heating power

80 KW

Furnace extractor air fans:

Add two extractor fans on the top of the kiln

Net weight(Kgs):

2500kg

Warranty:

1 year limited warranty

Certificate:

CE certified

Optional items:

PC data recorder, Exhauster port, Over temperature controller
